Standard:
Our camlock couplings are made to standard of A-A-59326(superseding MIL-C-27487) or DIN 2828. Casting method
Die casting or Gravity casting
Size:
From 1/2” to 12” Type:
A,B,C,D,DC,DP,E,F
Body material:
Aluminum( or heat treated)
Cam arm material:
Aluminum alloy
Stainless steel
Brass
Assembly:
Body+Gaskets+Handles+Pins+Pull Rings+Safety clips
Gasket material:
NBR (Temp Range ℃ - 30℃~ + 100℃)
EPDM (Temp Range ℃ - 50℃~ + 150℃)
Viton (Temp Range ℃ -20℃~ + 200℃)
PTFE envelop gasket (Temp Range ℃- 190℃~ +260℃)
Silicone (Temp Range ℃ -60℃~ + 200℃)
Other materials are available on request. Thread:
NPT
BSP (We usually produce the female thread parallel BSPP,malethread tapered BSPT)
